Significantly enhanced working capacity:
●Considerably increased digging force:
The bucket digging force (typically >65kN) and the arm force (typically >45kN) are far superior to SY75C, making it much easier to handle hard soil, clay, and even conditions with small stones.
●Greater digging depth and height:
The maximum digging depth is typically between 4.4-4.8 meters, and the maximum digging height is between 7.88.3 meters, enabling it to excel in deeper foundations, basements, trenches, and higher demands for earthwork shaping and loading operations.
●Larger standard capacity:
Typically between 0.32-0.38m³ (even larger), allowing for larger single-bucket digging volume and significantly improved truck loading efficiency.
●Stronger working devices and stability:
Equipped with reinforced heavy-duty boom and arm, a wider and more robust undercarriage, and an increase in overall weight, brings about excellent working stability, even when working on slopes or with heavy-duty attachments such as high-tonnage breakers.
| Bucket capacity: | 0.2-0.45(0.39)m³ |
| Rated power: | 60.7/2200 kw/rpm |
| Overall working weight: | 9180 kg |
| Travel speed: | 5.0/2.9 km/h |
| Climbing ability: | 70%/35° |
| Ground pressure: | 36 kPa |
| Bucket digging force: | 63.6 kN |
| Arm digging force: | 46.8 KN |
| x width x height (transport state) | 6560x2260x2720 mm |
| Track contact length: | 2340 mm |
| Track gauge: | 1810 mm |
| Minimum ground clearance: | 360 mm |
| Minimum turning radius (front end device | 1990 mm |
