Remanufactured High Quality Caterpillar 320D Excavator
$28000.00
Sales volume 700
Add to Favorites
Remanufactured High Quality Caterpillar 320D₂ Excavator
$32000.00
Freight
Ocean shipping, Land transportation
Quantity
Product details
| Working weight of the whole machine (kg) | 20930 |
| Bucket capacity (m³) | 1 |
| Boom length (mm) | 5700 |
| Fighter length (mm) | 2900 |
| Origin | Xuzhou |
| Tonnage (tons) | 20 |
| Power | Traditional Power |
| Bucket | backhoe |
| Manufacturer | joint venture/import |
| Power | Traditional Power |
| Rotation speed (rpm) | 11.5 |
| Walking speed (km/h) | 3.5/5.7 |
| Climbing capacity (%) | 70/35° |
| Grounding specific voltage (Kpa) | 6 |
| Bucket excavation force (kN) | 140.1 |
| Stick excavation force (kN) | 106.4 |
| Engine model | Carter C6.4ACERT |
| Rated power (kw/rpm) | 103/2000 |
| Displacement (L) | 6.37 |
Number of cylinders (pieces) | 6 |
| Bore x stroke (mm) | 102 x 130 |
| Cooling method | water cooling |
| Maximum flow rate of main pump (l/min) | 205 |
| Working hydraulic oil circuit (Mpa) | 35 |
| Walking hydraulic circuit (Mpa) | 35 |
| Swivel hydraulic circuit (Mpa) | 25 |
| Pipeline oil circuit (MPa) | 3.9 |
| Boom cylinder - number × cylinder bore × stroke (mm) | 2-120×1260 |
| Rod cylinder - number × cylinder bore × stroke (mm) | 1-140×1504 |
| Bucket cylinder - number × cylinder bore × stroke (mm) | 1-120×1104 |
| Is the hydraulic crushing pipeline standard | NO |
| Fuel tank (L) | 410 |
| Hydraulic fuel tank (L) | 120 |
| Hydraulic system (L) | 260 (including fuel tank) |
| Engine oil replacement quantity (L) | 30 |
Coolant (L) | 25 |
| Total transport length (mm) | 9460 |
| Total transport width (mm) | 2800 |
| Total transportation height (mm) | 3050 |
| Cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1020 |
| Track grounding length (mm) | 3265 |
| Total length of track (mm) | 4075 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
Track gauge (mm) | 2200 |
| Minimum ground clearance (mm) | 450 |
| Rear end slewing radius (mm) | 2750 |
Maximum excavation radius of shutdown surface (mm) | 9850 |
| Maximum excavation depth (mm) | 6710 |
| Maximum excavation height (mm) | 9840 |
| Maximum unloading height (mm) | 6500 |
| Maximum vertical excavation depth (mm) | 6180 |
| Maximum effective digging depth (mm) | 6540 |
| Bullsplate width × height (mm) | No bulldozer shovel |
| Bulldozer lift or push deep (mm) | no bulldozer |
