● The box body adopts reinforced beams and high-strength steel plate welded into a solidframe structure, made of high-quality Q345 special steel of Wuhan lron and Steel, with foursides and five bottoms, and a curved box with an overall side plate, which is beautiful inappearance, with good stress and no deformation; the push shovel consists of a rectangulartube skeleton and folded panel, which not only is lightweight, but also makes the garbageuniformly distributed, and the unloading of materials is clean and thorough.

● The weld seam of the box body adopts the first robot automated welding process in China,which does not scrape the dust and does not leak water, the box body has beautifulappearance, strong pressure bearing, firm structure, larger loading volume, and the boxbody is equipped with a sewage tank on the side.

● The key components of the electric-hydraulic system adopt famous brands: assembled withJiangsu Zhongmei/Weissenbole multi-way valves, Anhui Anhui Wanli/Chanyuan hydraulic oilpumps, Siemens PLC control system (optional CAN) (a total of two control boxes) withremote control, Jiangsu Feida/Hubei Bole hydraulic cylinders. All seals of the cylinder adoptHALLITE brand imported from Britain to ensure the service life of the cylinder. in thehydraulic system of lifting filler, a two-way balance valve is set. The valve not only ensuresthe smooth descent of the filler, but also isolates the direct connection between the liftingcylinder and the hydraulic hose, so that even if the hose bursts, the filler won't fall suddenly.which improves the safety of use.

● The tail feeding turning mechanism is widened and thickened, the bushing of the turningmechanism adopts quenching processing technology, and the main pin of the turning armadopts through-through double-sided welding technology, which is durable and won't bebroken.

● Filler assembly mainly consists of filler shell, skateboard, scraper and other components, fillerchute using high-strength wear-resistant material cold bending molding, skateboard onboth sides of the whole nylon slider, with self-lubricating, high stability, easy maintenance.wear resistance is better; scraper force parts using local strengthening treatment, thestructure of a solid. The lower arc plate is made of high-strength wear-resistant material,and there is a water leakage port on the arc plate, which is convenient for the internalsewage of the filler to flow into the lower sewage storage box, avoiding sewage leakage inthe process of transportation, and there is a large-capacity sewage storage box set in thelower part of the filler, and there are large-diameter galvanized sewage discharge ports onboth sides of the sewage box.
