Export Brand New Excavator DEVELON DX220(LC)A-2M
$78500.00
Sales volume 490
Application scenarios
●Mining:
With powerful digging force and durable working devices, it can efficiently dig ore, load and unload materials, etc. in heavy- operations such as mines.
●Large earthwork projects:
With a larger bucket capacity and powerful power, it can quickly complete large-scale earthwork operations such as digging, transporting and leveling.
●Water conservancy and hydropower projects:
Used for operations such as digging river channels, building dams, and cleaning reservoirs, and can adapt to hydraulic conditions.
| Basic parameters | |
| Machine weight: | 37,500kg |
| Standard bucket capacity: | 1.9m³ |
| Rated power : | 212kW/2000rpm |
| Engine parameters | |
| Model: | Isuzu 6HK1 |
| Type: | Direct injection, 6-cylinder -stroke, turbocharged intercooled, water-cooled |
| Displacement: | 7.79L |
| Maximum torque: | 1080Nm/150rpm |
| Performance parameters | |
| Travel speed: | 5.5/3.5km/h |
| Climbing capacity: | 70% (35°)Turntable speed: 8.8rpm |
| Ground pressure: | 8.8kPa |
| Bucket digging force: | 235kN |
| Arm digging force | 210kN |
| Fuel and coolant capacity | |
| Fuel tank: | 620L |
| Engine oil: | 41L |
| Coolant: | 8L |
| Travel reducer gear oil: | 2×8.5L |
| Turntable reducer gear oil: | 10.5L |
| Machine dimensions | |
| Total (in transport): | 11425mm |
| Total width: | 3190mm |
| Total height (in transport): | 3825mm |
| Upper: | 3230mm |
| Total height (top of the cab): | 3440mm |
| Standard track plate width: | 600mm |
| Track gauge | 2590mm |
| Minimum ground clearance: | 550mm |
| Tail swing radius: | 3610mm |
| Track ground contact length: | 4140mm |
| Track length: | 5100mm |
| Working range | |
| Maximum digging radius: | 10750mm |
| Maximum digging depth: | 7155mm |
